IC695ETM001-CC Product Description

The GE IC695ETM001-CC is a high-performance Ethernet communication module engineered for the PACSystems RX3i platform, purpose-built to support energy-aware automation architectures in demanding industrial environments. By offloading Ethernet communication tasks from the CPU backplane, the IC695ETM001-CC reduces processor overhead, shortens scan cycle times, and enables tighter coordination between energy-consuming field devices — directly contributing to measurable reductions in idle-state power draw and thermal load across the production line.

In a fully integrated smart factory, the IC695ETM001-CC serves as the Ethernet backbone for real-time energy data exchange between the GE PACSystems RX3i CPU — IC695CPE305 and downstream energy-consuming assets. When paired with the IC695PSD040 power supply module, the system maintains stable backplane voltage under variable load conditions, preventing voltage sag events that can trigger unnecessary drive restarts and associated energy spikes.

The module communicates over SRTP and Modbus TCP with ABB ACS880 series variable frequency drives and Siemens SINAMICS G120 drives, enabling the PLC to issue speed-reference commands that align motor output with actual production demand rather than running at fixed rated speed. This demand-responsive drive control is one of the most impactful levers for reducing motor energy consumption — motors operating at 80% speed consume approximately 51% of the energy required at full speed, following the affinity law.

For servo-axis applications, the IC695ETM001-CC coordinates with GE Fanuc Series 90-30 servo amplifier modules and third-party EtherNet/IP-capable servo drives via protocol gateway bridges, synchronising axis motion profiles with production line throughput targets. This prevents servo systems from holding torque unnecessarily during idle dwell periods, reducing both electrical consumption and thermal stress on drive components.

Power monitoring data from Schneider Electric PowerLogic ION7650 power quality meters and Carlo Gavazzi EM24 energy analysers is aggregated through the IC695ETM001-CC's Ethernet port into the SCADA layer — typically GE CIMPLICITY or iFIX HMI/SCADA — where energy KPIs such as kWh per unit produced, peak demand windows, and power factor trends are visualised in real time. This closed-loop visibility allows operators to schedule high-load operations outside peak tariff windows, directly reducing energy procurement costs.

On the I/O side, the module works in concert with GE IC694MDL754 discrete output modules and IC695ALG600 analogue input modules to capture sensor feedback from current transformers, temperature probes, and pressure transducers. This field data feeds predictive maintenance algorithms that identify abnormal energy signatures — such as elevated motor current indicating bearing wear — before they escalate into unplanned downtime events that disrupt production rhythm and waste energy through emergency restarts.

The IC695ETM001-CC enables a structured approach to factory energy optimisation by acting as the real-time communication bridge between the control layer and the energy management system. In multi-zone production environments, the module supports segmented network topologies that isolate high-bandwidth drive communication traffic from standard PLC I/O polling, preventing network congestion that can introduce latency into time-critical energy control loops.

By enabling the RX3i controller to receive live load data from power monitoring modules and transmit corrective setpoints to variable frequency drives within a single scan cycle, the IC695ETM001-CC supports load shedding strategies that automatically reduce non-critical motor speeds during peak demand periods. This capability is particularly valuable in facilities operating under demand-charge tariff structures, where brief peaks in consumption can disproportionately inflate monthly energy bills.

Thermal load management is another key benefit. By coordinating drive ramp profiles and motor start sequences through the Ethernet network rather than relying on local drive logic, the IC695ETM001-CC helps distribute mechanical and electrical stress across the production cycle. Staggered motor starts reduce inrush current peaks, lower transformer loading, and extend the service life of switchgear and drive components — all of which translate into lower total cost of ownership and reduced maintenance-related downtime.

For facilities pursuing ISO 50001 energy management certification or implementing IEC 61968-compliant energy data exchange, the IC695ETM001-CC's support for open Ethernet protocols provides the connectivity foundation required to integrate plant-floor energy data with enterprise-level energy management systems (EMS) and ERP platforms. This end-to-end data visibility is essential for establishing energy baselines, tracking improvement projects, and demonstrating compliance with regulatory reporting requirements.

Every IC695ETM001-CC unit supplied by NANKMOS is sourced from verified distribution channels, subjected to functional communication testing prior to shipment, and covered by a 12-month warranty. Stock is maintained for immediate dispatch, minimising lead times for maintenance replacements and system expansion projects.

Q1: How does the IC695ETM001-CC contribute to measurable energy savings on the production line? By offloading Ethernet communication from the RX3i CPU, the module shortens PLC scan cycles and enables faster closed-loop response to energy data from power monitoring devices. This allows the controller to issue real-time speed corrections to variable frequency drives, reducing motor energy consumption during low-demand periods and preventing unnecessary full-speed operation.

Q2: Is the IC695ETM001-CC compatible with third-party SCADA and HMI systems? Yes. The module supports SRTP, Modbus TCP, and Ethernet Global Data (EGD) protocols, making it compatible with a wide range of SCADA platforms including GE CIMPLICITY, iFIX, Wonderware, and OPC-UA-capable HMI systems. It can also interface with energy management gateways that aggregate data for ISO 50001 reporting.

Q3: Can this module replace an existing IC695ETM001 (non-CC variant) without hardware changes? The IC695ETM001-CC is the conformal-coated variant of the IC695ETM001, designed for environments with elevated humidity or airborne contaminants. It is functionally equivalent and fits the same RX3i backplane slot. Firmware and configuration files from the standard variant are compatible, making replacement straightforward with no rack modifications required.

Q4: What is the warranty coverage and pre-shipment testing process? All IC695ETM001-CC units supplied by NANKMOS carry a 12-month warranty covering manufacturing defects and functional failures under normal operating conditions. Each unit undergoes communication functionality verification and visual inspection before dispatch. In-stock units are available for same-week shipment, supporting urgent maintenance and minimising production downtime.
