ABB 117539 DSQC 697, 3HAC037084-001/0, 739176 SST-DN4-PCI 79

Product Details

117539 DSQC 697, 3HAC037084-001/0, 739176 SST-DN4-PCI 790-073306-109 Product Description

The ABB DSQC 697 (3HAC037084-001) is a high-performance DeviceNet PCI interface card engineered for ABB IRC5 robot controller systems. Designed to serve as the critical communication bridge between field-level devices and upper-level control architectures, this module enables seamless, real-time data exchange across complex industrial automation environments. Whether deployed in automotive assembly lines, semiconductor fabrication, petrochemical processing, or smart factory integration projects, the DSQC 697 delivers the protocol reliability and network stability that modern Industry 4.0 applications demand.

As a DeviceNet-compliant PCI card, the DSQC 697 connects the IRC5 robot controller directly into the plant-wide fieldbus network, enabling the robot to communicate with PLCs, remote I/O modules, HMI panels, SCADA systems, and distributed control nodes without protocol conversion bottlenecks. Its plug-in PCI form factor ensures straightforward installation into the IRC5 controller's main computer unit, while its firmware-level DeviceNet stack guarantees deterministic, low-latency data transmission — a non-negotiable requirement in high-speed robotic welding, pick-and-place, and precision assembly applications.

In a fully connected smart factory, the DSQC 697 sits at the intersection of robot-level execution and plant-level intelligence. The data flow begins at the sensor and actuator layer — proximity sensors, vision systems, torque transducers, and servo drives — all feeding real-time signals into the DeviceNet fieldbus. The DSQC 697 collects these signals within the IRC5 controller and routes them upstream to the plant's PLC backbone, typically an ABB AC500 PLC or a third-party Siemens S7-300/S7-1500 controller managing production sequencing.

From the PLC layer, data flows into the SCADA and MES tier via industrial Ethernet switches — such as the ABB AF series managed switches or Hirschmann MICE series — which aggregate fieldbus data from multiple robot cells and production islands into a unified Ethernet backbone. HMI panels, including ABB CP600 series operator panels, display real-time robot status, cycle counts, fault codes, and production KPIs drawn directly from the DeviceNet data stream managed by the DSQC 697.

For remote I/O expansion, the DSQC 697 network supports ABB DSQC 652 digital I/O modules and DSQC 651 analog I/O boards connected as DeviceNet slave nodes, extending the robot's I/O capacity without additional cabling infrastructure. This architecture is particularly valuable in multi-robot cells where a single DeviceNet master — the DSQC 697 — orchestrates I/O data from multiple slave nodes across the production line.

Edge gateway devices, such as the HMS Anybus X-gateway DeviceNet to PROFINET or similar protocol bridges, can be inserted between the DeviceNet segment and the plant's PROFINET or EtherNet/IP backbone, enabling the DSQC 697's data to reach cloud-based analytics platforms and digital twin systems. Variable frequency drives (VFDs) — including ABB ACS880 series drives — connected as DeviceNet nodes report speed, torque, and fault data through the same network segment, giving SCADA operators a unified view of both robot and drive performance in real time.

Data visualization dashboards built on platforms like Ignition SCADA or ABB Ability™ pull aggregated DeviceNet data through OPC-UA gateways, enabling production managers to monitor robot uptime, cycle efficiency, alarm histories, and predictive maintenance indicators from any connected workstation or mobile device — completing the smart factory data chain from field device to enterprise dashboard.

Many industrial sites operating ABB IRC5 robots face persistent data connectivity challenges: protocol fragmentation between DeviceNet field devices and Ethernet-based SCADA systems, data silos where robot performance metrics are isolated from plant-wide OEE dashboards, and limited remote diagnostic capability when faults occur outside business hours.

The DSQC 697 directly addresses protocol unification by providing a native DeviceNet interface within the IRC5 controller, eliminating the need for external protocol converters between the robot and DeviceNet field devices. This reduces network latency, simplifies wiring, and ensures that all DeviceNet nodes — sensors, I/O modules, drives, and safety relays — communicate with the robot controller through a single, deterministic data path.

For production line transparency, the DSQC 697 enables continuous cycle data reporting to SCADA systems, allowing supervisors to track robot utilization rates, detect abnormal cycle times, and trigger maintenance alerts before unplanned downtime occurs. Alarm tracking is enhanced by the DeviceNet's built-in error detection and node health monitoring, which surfaces device-level faults — such as a failed proximity sensor or a disconnected I/O module — directly in the SCADA alarm management console.

System scalability is a core strength of the DeviceNet architecture supported by the DSQC 697. As production capacity expands, additional DeviceNet slave nodes can be added to the network segment without hardware changes to the robot controller, supporting phased factory expansion projects with minimal integration risk. All units are pre-tested before shipment and backed by a 12-month warranty, ensuring operational confidence from day one of deployment.

Q1: What is the communication latency of the DSQC 697 on a DeviceNet network?The DSQC 697 supports DeviceNet transmission speeds of 125 kbps, 250 kbps, and 500 kbps. At 500 kbps with optimized network configuration, cyclic data exchange latency is typically under 5 milliseconds per node, meeting the real-time requirements of high-speed robotic applications.

Q2: Is the DSQC 697 compatible with both ABB RobotWare 5 and RobotWare 6?The DSQC 697 is designed for ABB IRC5 controller platforms and is compatible with RobotWare versions supported by the IRC5 hardware generation. Compatibility with specific RobotWare releases should be confirmed against ABB's product lifecycle documentation for your controller revision.

Q3: Can the DSQC 697 network be extended to connect with PROFINET or EtherNet/IP SCADA systems?Yes. Protocol gateway devices — such as HMS Anybus or Moxa MGate series — can bridge the DeviceNet segment managed by the DSQC 697 to PROFINET, EtherNet/IP, or Modbus TCP networks, enabling full SCADA and MES integration without modifying the robot controller configuration.

Q4: What does the 12-month warranty cover, and is pre-shipment testing performed?Every DSQC 697 unit undergoes functional testing prior to shipment to verify DeviceNet communication integrity and PCI interface operation. The 12-month warranty covers hardware defects and communication failures under normal operating conditions, with technical support available throughout the warranty period.
