GE Automation & Controls IC200CPUE05-EH CPU Module

Product Details

IC200CPUE05-EH Product Description

The GE IC200CPUE05-EH is a high-performance Ethernet CPU module engineered for the VersaMax modular PLC platform, delivering deterministic scan-cycle execution, integrated Ethernet communications, and robust I/O coordination across distributed control architectures. Designed for demanding industrial environments, this CPU module serves as the central processing and coordination node within multi-layer automation systems — managing control logic, I/O data exchange, network communications, and diagnostic reporting from a single, compact module.

In modern industrial control architectures, the CPU is not an isolated component — it is the orchestration hub that binds the control layer, I/O layer, communications layer, power layer, and HMI layer into a coherent, responsive system. The IC200CPUE05-EH fulfills this role with precision, supporting ladder logic and structured text programming via GE's Proficy Machine Edition software environment, enabling engineers to implement modular, scalable, and maintainable control strategies across manufacturing, power generation, petrochemical, water treatment, and process control applications.

Every IC200CPUE05-EH unit supplied by NANKMOS is pre-shipment tested, verified against factory specifications, and backed by a 12-Month Warranty, ensuring operational confidence from day one of deployment.

The IC200CPUE05-EH achieves its full potential when deployed within a complete VersaMax automation platform. At the power layer, the IC200PWR002 or IC200PWR101 power supply modules provide stable, regulated DC power to the CPU and all I/O modules on the carrier base, ensuring voltage integrity across the entire rack. The IC200CHS002 and IC200CHS005 carrier bases form the backplane layer, physically and electrically interconnecting the CPU with discrete and analog I/O modules.

At the I/O layer, modules such as the IC200MDL640 (16-point 24VDC discrete input), IC200MDL740 (16-point discrete output), and IC200ALG260 (analog input module) expand the system's sensing and actuation capability, feeding real-time field data directly into the CPU's reference tables for logic execution. For applications requiring signal isolation between field devices and the control system, signal isolators and terminal modules mounted adjacent to the VersaMax carrier ensure clean, noise-free signal transmission.

At the communications layer, the IC200CPUE05-EH's integrated Ethernet port supports Ethernet Global Data (EGD) for peer-to-peer data exchange between multiple VersaMax CPUs or with GE PACSystems RX3i controllers, enabling distributed control architectures without additional communication modules. For legacy serial device integration, the RS-232/RS-485 port supports Modbus RTU communication with drives, meters, and remote I/O stations.

At the HMI layer, the CPU communicates natively with GE QuickPanel+ operator interface terminals via SRTP over Ethernet, providing operators with real-time process visualization, alarm management, and parameter adjustment without additional protocol converters. For SCADA integration, the Modbus TCP capability allows direct connection to supervisory systems including Wonderware, iFIX, and third-party OPC-UA gateways.

For redundancy-critical applications, the IC200CPUE05-EH can be deployed in hot-standby configurations using GE's redundancy communication modules, ensuring seamless CPU failover in power generation, water treatment, and continuous process industries where unplanned downtime is unacceptable.

Power Generation: The IC200CPUE05-EH manages auxiliary system control in gas turbine and steam turbine plants — coordinating cooling water pumps, lube oil systems, and fuel valve sequencing with deterministic scan cycles and Ethernet-based SCADA integration.

Petrochemical & Oil and Gas: In refinery and pipeline control applications, the CPU's Modbus TCP capability enables direct integration with flow computers, pressure transmitters, and motor control centers, supporting both local panel control and remote supervisory monitoring.

Water and Wastewater Treatment: Municipal water treatment facilities deploy the IC200CPUE05-EH for pump station automation, chemical dosing control, and SCADA telemetry — leveraging EGD peer communications to synchronize distributed pump stations across large geographic areas.

Manufacturing and Packaging Lines: In discrete manufacturing environments, the CPU coordinates conveyor sequencing, robotic cell interfacing, vision system triggers, and reject gate control — all within a single VersaMax rack that minimizes panel footprint and wiring complexity.

Mining and Metals: The IC200CPUE05-EH's wide operating temperature range and robust construction make it suitable for crusher control, conveyor belt management, and ore processing automation in harsh mining environments where reliability and long-term maintainability are paramount.

Q1: Is the IC200CPUE05-EH compatible with existing VersaMax I/O modules and carrier bases already installed in my control cabinet? Yes. The IC200CPUE05-EH is fully compatible with all VersaMax modular I/O modules (IC200MDL and IC200ALG series) and carrier bases (IC200CHS002, IC200CHS005). It slots directly into any VersaMax carrier without hardware modification, making it an ideal drop-in CPU upgrade for existing installations. Configuration is performed via Proficy Machine Edition, which supports online program transfer without disrupting I/O module operation.

Q2: Can the IC200CPUE05-EH communicate simultaneously with a GE QuickPanel HMI and a SCADA system over Ethernet? Yes. The integrated 10/100 Mbps Ethernet port supports concurrent SRTP sessions (for HMI communication) and Modbus TCP connections (for SCADA or third-party system integration). Ethernet Global Data (EGD) can also run simultaneously for peer-to-peer data exchange with other VersaMax or PACSystems controllers, enabling a fully networked, multi-node control architecture from a single Ethernet port.

Q3: What does the 12-Month Warranty cover, and how does NANKMOS ensure the IC200CPUE05-EH is ready for immediate deployment? Every IC200CPUE05-EH supplied by NANKMOS undergoes pre-shipment functional testing — verifying CPU boot sequence, Ethernet port connectivity, serial port operation, and I/O bus communication — before dispatch. The 12-Month Warranty covers manufacturing defects and functional failures under normal operating conditions. In-stock units are available for immediate shipment, minimizing project lead times and ensuring your control architecture remains on schedule.
