Honeywell CC-INWE01 Ethernet Interface Module

Product Details

CC-INWE01 Product Description

The Honeywell CC-INWE01 is a high-performance Ethernet Interface Module engineered for seamless integration within the Honeywell Experion PKS C300 Distributed Control System (DCS) architecture. Designed to serve as the critical communication bridge between the controller layer and the plant-wide Ethernet backbone, the CC-INWE01 ensures deterministic data exchange, real-time diagnostics, and robust network redundancy across multi-tier industrial automation platforms. Whether deployed in greenfield projects or legacy system expansions, this module delivers the connectivity precision and long-term reliability demanded by mission-critical process industries.

The CC-INWE01 does not operate in isolation — it functions as the Ethernet communication spine within a fully coordinated Honeywell Experion PKS C300 automation architecture. In a typical deployment, the module interfaces directly with the C300 Controller (CC-PCNT01), which handles real-time process execution and loop control. The controller communicates upstream to the Experion server via the FTE network, where the CC-INWE01 manages packet routing, network health monitoring, and failover switching.

On the I/O layer, the CC-INWE01 works in concert with CHARM I/O modules (such as the CC-TDIL01 digital input and CC-TAOX11 analog output CHARMs) mounted on CHARM I/O Assemblies (CIOM-A), ensuring that field signals are accurately digitized and transmitted through the control network without latency or data loss. The CC-PWRR01 redundant power supply module provides the stable 24 VDC rail required by the CC-INWE01 and adjacent modules, while the CC-SCMB02 system cabinet module bus maintains backplane signal integrity across the chassis.

For plants requiring high-availability architectures, the CC-INWE01 supports dual-redundant Ethernet ring configurations in conjunction with Honeywell FTE switches (FTESW-8), enabling automatic failover in under 50 milliseconds — a critical requirement for continuous process industries. Communication gateways such as the CC-GTWY01 Modbus/OPC gateway can be integrated alongside the CC-INWE01 to bridge legacy field devices into the modern Experion PKS environment without disrupting the primary control loop.

At the HMI layer, operator stations running Experion PKS Station software receive real-time process data routed through the CC-INWE01's Ethernet interface, enabling operators to monitor alarms, trends, and control outputs with sub-second refresh rates. For remote diagnostics and asset management, the module integrates with Honeywell Asset Manager and supports HART pass-through for field device calibration without loop interruption.

The CC-INWE01 also plays a key role in system expansion scenarios. When additional C300 controller pairs or Series C I/O Link Interface modules (CC-LINK01) are added to scale the control architecture, the CC-INWE01 ensures that the expanded network segments maintain consistent communication timing and redundancy profiles. This modular scalability makes it an ideal choice for phased plant expansions and multi-unit process trains.

Oil & Gas / Petrochemical: In upstream and downstream hydrocarbon processing, the CC-INWE01 serves as the Ethernet backbone interface for C300-based safety instrumented systems and process control loops. Its support for FTE redundancy ensures continuous operation during network faults, meeting the uptime requirements of distillation columns, compressor trains, and pipeline SCADA integration points.

Power Generation & Utilities: Thermal, hydro, and combined-cycle power plants rely on the CC-INWE01 to maintain real-time communication between turbine control modules, boiler management systems, and plant-wide DCS servers. The module's dual-port Ethernet design supports the high-bandwidth data throughput required for fast-response load-following control strategies.

Chemical & Pharmaceutical Manufacturing: Batch and continuous process facilities use the CC-INWE01 to integrate recipe management systems, PAT (Process Analytical Technology) instruments, and regulatory data historians into the Experion PKS platform. Its deterministic communication timing supports 21 CFR Part 11 compliant data logging and audit trail generation.

Water & Wastewater Treatment: Municipal and industrial water treatment plants deploy the CC-INWE01 to connect distributed pump stations, chemical dosing systems, and filtration control loops into a centralized C300 DCS. The module's wide operating temperature range and humidity tolerance make it suitable for outdoor and semi-enclosed panel installations.

Mining & Metals / Pulp & Paper: In high-vibration, high-dust environments, the CC-INWE01's robust industrial-grade construction ensures reliable Ethernet communication for conveyor control, crusher automation, and kiln temperature management systems. Its compatibility with the C300 chassis backplane simplifies spare parts management and reduces mean time to repair (MTTR) during unplanned outages.

Q1: Is the CC-INWE01 compatible with both redundant and simplex C300 controller configurations? Yes. The CC-INWE01 supports both simplex and redundant C300 controller pair configurations. In redundant deployments, two CC-INWE01 modules are installed — one per controller — and the FTE network automatically manages primary/secondary switchover without operator intervention. In simplex configurations, a single CC-INWE01 provides standard Ethernet connectivity to the Experion PKS server. Both configurations are supported within the same chassis backplane, allowing future upgrades from simplex to redundant without hardware replacement.

Q2: What firmware and Experion PKS software versions are required for full Contextual Integration with the CC-INWE01? The CC-INWE01 achieves full Contextual Integration with Experion PKS R400 and later releases. For optimal performance and access to advanced diagnostic features — including network health dashboards and predictive maintenance alerts — Experion PKS R510 or higher is recommended. Firmware updates for the CC-INWE01 are delivered through the standard Experion software update mechanism and do not require module removal or loop shutdown, minimizing maintenance windows and supporting long-term system lifecycle management.

Q3: What does the 12-Month Warranty cover, and what is the pre-shipment testing process? Every CC-INWE01 supplied by NANKMOS is covered by a 12-Month Warranty against manufacturing defects and functional failures under normal operating conditions. Prior to shipment, each unit undergoes a comprehensive functional test protocol that includes power-on self-test (POST) verification, Ethernet port continuity and link-speed testing, backplane communication handshake validation, and firmware version confirmation. Units that do not pass all test criteria are quarantined and not shipped. In the event of a warranty claim, NANKMOS provides advance replacement service to minimize system downtime, with full RMA documentation and failure analysis reporting available upon request.
