Matrox METEOR/RGB PCI 571-03 Frame Grabber

Product Details

METEOR/RGB PCI 571-03 Product Description

The Matrox METEOR/RGB PCI 571-03 is a high-performance PCI-bus RGB frame grabber engineered for industrial machine vision, real-time image acquisition, and seamless integration into smart factory data architectures. Designed to bridge the gap between analog visual signals and digital automation networks, the 571-03 captures, digitises, and transmits RGB video data from cameras, sensors, and inspection systems directly into SCADA platforms, HMI displays, and upper-level MES/ERP systems — forming a critical node in the factory-wide data chain.

In modern smart manufacturing environments, visual data is no longer isolated. The Matrox Meteor/RGB PCI 571-03 connects analog RGB camera outputs to the PCI bus of industrial PCs and vision controllers, enabling real-time image processing, defect detection, dimensional measurement, and quality inspection — all feeding structured data upstream to supervisory control layers. Whether deployed on a standalone inspection station or integrated into a multi-node vision network, the 571-03 delivers the signal fidelity and acquisition speed that industrial automation demands.

The Matrox METEOR/RGB PCI 571-03 sits at the front end of the factory visual data chain. In a typical smart factory deployment, analog RGB cameras mounted on conveyor lines, robotic arms, or inspection gantries feed live video signals into the 571-03 frame grabber installed in an industrial IPC. The IPC, running Matrox Imaging Library (MIL) or compatible vision software, processes each captured frame in real time — performing edge detection, colour analysis, barcode reading, or dimensional verification — and outputs structured pass/fail data or measurement values to the automation network.

This structured data flows downstream via the host IPC's Ethernet port to a Siemens S7-1500 PLC or Allen-Bradley ControlLogix controller, which acts on inspection results to trigger reject mechanisms, adjust conveyor speed via a Siemens SINAMICS G120 variable frequency drive, or update production counters. Simultaneously, the vision data is forwarded to a Weintek cMT SCADA/HMI terminal or Advantech WebAccess SCADA platform, where operators monitor live inspection images, trend defect rates, and receive alarm notifications in real time.

For remote diagnostics and multi-site visibility, the inspection data is aggregated by an Advantech WISE-5000 edge gateway or Moxa UC-8100 edge computing controller, which normalises the data into OPC-UA or MQTT format and pushes it to cloud-based MES or ERP dashboards. This enables plant managers to monitor quality KPIs, defect trends, and line throughput from any location without requiring on-site access.

In multi-camera inspection cells, the 571-03 works alongside Matrox Solios or Matrox Radient multi-channel frame grabbers to handle parallel camera streams, while a Moxa EDS-308 industrial Ethernet switch ensures low-latency, deterministic network communication between vision controllers, PLCs, and SCADA servers. Remote I/O modules such as the Wago 750-352 PROFINET I/O coupler extend digital signal collection from proximity sensors, photoelectric barriers, and encoder feedback into the same network fabric — creating a unified, transparent data environment across the entire production line.

The result is a complete visual data pipeline: from analog RGB signal capture at the camera, through real-time frame processing in the IPC, to structured quality data flowing into PLCs, HMIs, SCADA systems, and cloud analytics — all anchored by the reliable acquisition performance of the Matrox METEOR/RGB PCI 571-03.

Protocol Fragmentation: Many legacy production lines rely on analog RGB cameras that cannot natively communicate with modern digital automation networks. The Matrox METEOR/RGB PCI 571-03 resolves this by digitising analog video at the source, converting visual information into structured data that PLCs, SCADA systems, and MES platforms can consume directly — eliminating the protocol gap between legacy imaging hardware and modern industrial networks.

Data Silos in Visual Inspection: Without a capable frame grabber, inspection results often remain isolated within standalone vision PCs, invisible to the broader automation system. The 571-03 enables inspection data to be exported via the host IPC to Ethernet-connected SCADA and HMI systems, breaking down data silos and making quality metrics visible across the entire factory network in real time.

Remote Monitoring Limitations: Traditional machine vision setups require on-site engineers to review inspection results. By integrating the 571-03 into an edge gateway architecture — using platforms such as the Advantech WISE-5000 or Moxa UC-8100 — inspection data and alarm events can be transmitted remotely, enabling off-site engineers to diagnose quality issues, review defect images, and adjust inspection parameters without travelling to the production floor.

Production Line Transparency: The 571-03 supports continuous, uninterrupted frame capture, ensuring that every unit passing through the inspection station is evaluated and logged. Combined with SCADA trending tools and MES integration, this creates a fully transparent production record — enabling traceability, audit compliance, and data-driven process optimisation across shifts and production batches.

System Scalability: As production lines expand, additional camera channels can be added by deploying supplementary Matrox frame grabbers — such as the Matrox Solios eA/XA series — within the same IPC or vision network, scaling inspection capacity without redesigning the underlying data architecture. The standardised PCI interface and MIL software ecosystem ensure forward compatibility as automation requirements evolve.

Q1: Does the Matrox METEOR/RGB PCI 571-03 support real-time image transmission to SCADA systems? Yes. The 571-03 captures analog RGB video and transfers digitised frames to the host IPC in real time via the PCI bus. The host IPC can then forward processed inspection data — including pass/fail results, measurement values, and alarm events — to SCADA platforms such as Advantech WebAccess, Ignition, or WinCC via standard Ethernet/OPC-UA communication, enabling live visual monitoring at the supervisory level.

Q2: Is the 571-03 compatible with modern industrial network architectures including PROFINET and OPC-UA? The 571-03 itself uses the PCI bus for host communication; network protocol integration (PROFINET, OPC-UA, MQTT) is handled at the host IPC level. When the IPC is connected to a PROFINET-capable PLC or an OPC-UA server, inspection results from the 571-03 can be seamlessly published to the automation network, making it fully compatible with modern industrial communication standards through the host system.

Q3: What remote diagnostic capabilities does the 571-03 support in a smart factory environment? When integrated with an edge gateway such as the Advantech WISE-5000 or Moxa UC-8100, the 571-03's inspection outputs can be transmitted to remote monitoring dashboards via MQTT or OPC-UA. Engineers can review defect trends, alarm histories, and inspection statistics remotely — reducing unplanned downtime and enabling predictive maintenance without requiring physical access to the production line.

Q4: What warranty and pre-shipment testing does the Matrox METEOR/RGB PCI 571-03 carry? Every Matrox METEOR/RGB PCI 571-03 unit supplied by NANKMOS is covered by a 12-Month Warranty and undergoes functional testing prior to shipment. Stock is maintained for prompt delivery, and our technical team is available to support integration, compatibility verification, and commissioning queries. Contact us at [email protected] or +86 18359268345 for availability and RFQ.
